| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 39-30-2032 |
| Color: | Natural |
| Series: | 5566 - Mini-Fit Jr. |
| Amperage: | 9 A |
| Connector Type: | Mini-Fit Jr. |
| Number of Contacts: | 3 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Body Orientation: | Straight |
| Pitch: | 4.2 mm |
| Voltage: | 600 V |
| Material: | Nylon |
| Orientation: | Vertical |
| Keying: | No |
| Tail Length: | 3.5 mm |
| Operating Temperature Range: | -40 - 105 °C |
| Contact Mating Area Plating: | Gold |
| Contact Mating Area Plating Thickness: | .762 µm |
| Number of Contacts Loaded: | 3 |
| Mating Cycles: | 30 |
| PCB Locator: | Yes |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| Contact Termination Plating Thickness: | 2.540 µm |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | 1.6 mm |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Matte Tin |
| Maximum Solder Process Temperature: | 240 °C |
| Lead Free Process Capability: | WAVE |
| Duration at Max. Process Temperature (seconds): | 005 |
| Max. Cycles at Max. Process Temperature: | 001 |
| Termination Pitch: | 4.2 mm |
| Glow Wire Capable: | No |
| Guide to Mating Part: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Surface Mount Compatible: | No |
| Breakaway: | No |
| Make First / Break Last: | No |
| Shroud Type: | Fully |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0039302032 5566-03A3GS-210 |
| SKU: | MOL39-30-2032 |
39-30-2032
Specifications
Detailed Description
The Molex Mini-Fit Jr. Vertical Header is a reliable and high-performance connector for your PCB assembly needs. With a 4.20mm pitch and featuring a single row design, it is perfect for space-saving applications. This specific model has 3 circuits, each with a gold-plated contact for excellent conductivity. The snap-in plastic peg PCB lock ensures secure and stable connection, while the straight body orientation allows for easy cable routing. Rated for up to 600V and 9A, this connector is suitable for a wide range of power and signal applications. With its nylon housing and matte tin termination plating, it offers durability and longevity, even in harsh environments. RoHS compliant and lead-free solder process capable, it meets international standards for environmental responsibility. Trust the Molex Mini-Fit Jr. 5566 series for your wire-to-board connectivity needs.
