70543-0106

ICC Number:	MOL70543-0106
Manufacturer:	Molex
Manufacturer Number:	70543-0106
Datasheet:	Datasheet
ECAD Model:

Description:

2.54mm Pitch SL Header, Single Row, Vertical, 3.05mm Pocket, Shrouded, 3.30mm Tail Length, 2 Circuits, 0.76µm Gold (Au) Selective Plating, Matte Tin (Sn) Tail Plating

More >>

Specifications

Attribute	Value
Product Category:	PCB Connectors PCB Headers & Receptacles
Manufacturer:	Molex
Manufacturer Part Number:	Molex 70543-0106
Gender:	Male
Number of Contacts:	2
Number of Rows:	1
Contact Material:	Brass, Phosphor Bronze
Contact Plating:	Gold
Pitch:	2.54 mm
Shroud Type:	Yes
Flammability Rating:	UL 94V-0
Current Rating:	3 A
Voltage Rating:	250 V
Operating Temperature:	-40 to 105 °C
Mounting Angle:	Straight
Mounting Type:	Through Hole
PCB Connector Type:	Header
SKU:	MOL70543-0106

Detailed Description

Introducing the 70543-0106, a high-performance PCB pin header connector designed for reliable wire-to-board or wire-to-wire connections. With a sleek black exterior and straight body orientation, this connector is not only visually appealing but also space-efficient. Featuring two contacts in a single row, each rated for 3A of current at 250V, it ensures robust power transmission. The gold-plated contact mating area guarantees low contact resistance and superior signal integrity. Constructed with high-temperature thermoplastic and tin-plated brass/phosphor bronze contacts, this connector is durable and suitable for operating in harsh environments ranging from -40 to 105°C. With RoHS compliance and lead-free soldering capability, it meets stringent environmental standards. Perfect for a wide range of applications, the 70543-0106 is a versatile and dependable connectivity solution.
