| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 15-29-1025 |
| Color: | Black |
| Series: | 7859 - C-Grid - C-Grid III - SL |
| Amperage: | 5 A |
| Connector Type: | C-Grid, C-Grid III, SL |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| Contact Material: | Phosphor Bronze |
| Material: | Polyester |
| Jumper/Shunt: | Shunt |
| Component Type: | Shunt |
| Packaging: | Bag |
| Operating Temperature Range: | -40 - 105 °C |
| Number of Contacts Loaded: | 2 |
| CSA Agency Certification: | LR19980 |
| UL Agency Certification: | E29179 |
| Lock to Mating Part: | No |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0015291025 7859-2A554N |
| SKU: | MOL15-29-1025 |
15-29-1025
Specifications
Detailed Description
The 15-29-1025 is a black C-Grid, C-Grid III, and SL connector featuring a jumper shunt for added versatility. With a low amperage rating of 5 A, this connector is suitable for various electronic applications. Constructed with durable phosphor bronze contacts and polyester housing, it ensures reliable performance in demanding environments. Certified by CSA (LR19980) and UL (E29179), it meets stringent quality standards. With two contacts loaded and rohs compliance, it offers efficient and environmentally friendly connectivity solutions. Perfect for PCB applications, this connector is in stock and ready to ship.
