| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 505565-0301 |
| Color: | Black |
| Series: | 505565 - Micro-Lock PLUS |
| Connector Type: | Micro-Lock PLUS |
| Gender: | Receptacle |
| Number of Contacts: | 3 |
| Number of Rows: | 1 |
| Pitch: | 1.25 mm |
| Material: | Polyester |
| Keying: | No |
| Packaging: | Bag |
| Operating Temperature Range: | -40 - 105 °C |
| Circuit Application: | Signal |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Board |
| UL Agency Certification: | E29179 |
| Termination Pitch: | 1.25 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Part Aliases: | 5055650301 |
| SKU: | MOL505565-0301 |
505565-0301
| Heilind Number: | MOL505565-0301 |
| Manufacturer: | Molex |
| Manufacturer Number: | 505565-0301 |
| Datasheet: | Product Literature |
| ECAD Model: | |
Description:
Micro-Lock PLUS Receptacle Housing, 1.25mm Pitch, Single Row, with Positive Lock, 3 Circuits, Black
More >>Specifications
Detailed Description
Introducing the 505565-0301 Micro-Lock PLUS Receptacle Housing, a crucial component for your signal circuit applications. With a single row design and a 1.25mm pitch, this black housing features a secure positive lock mechanism, ensuring reliable connections in your wire to board setups. Certified for UL agency standards and RoHS compliant, it guarantees safety and environmental responsibility. Operating efficiently in a wide temperature range from -40 to 105 °C, this housing is durable and versatile. Each package includes 3 circuits, with each contact polarized for easy mating. Trust in the Micro-Lock PLUS Connector System for high-quality performance in your electronic projects.
