| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 505431-1000 |
| Series: | 505431 - Micro-Lock PLUS |
| Amperage: | 1.5 A |
| Connector Type: | Micro-Lock PLUS |
| Gender: | Female |
| Termination Method: | Crimp or Compression |
| Contact Material: | Copper Alloy |
| Contact Plating: | Tin |
| Voltage: | 50 V AC/DC |
| Circuit Application: | Signal |
| Contact Mating Area Plating: | Tin |
| Mating Cycles: | 30 |
| Wire Size: | .049 - .136 mm², 26 AWG, 28 AWG, 30 AWG |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | .78 - 1.02 mm |
| Part Aliases: | 5054311000 |
| SKU: | MOL505431-1000 |
505431-1000
| Heilind Number: | MOL505431-1000 |
| Manufacturer: | Molex |
| Manufacturer Number: | 505431-1000 |
| Datasheet: | Application Specification |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the 505431-1000, a Micro-Lock PLUS Receptacle Terminal designed for optimal performance in low-power applications. With a tin-plated copper alloy construction, this female terminal ensures reliable conductivity for 26-30 AWG wires. Featuring a crimp or compression termination method, it offers easy installation onto .78-1.02 mm wire insulation. Rated for 1.5 A and 50 V AC/DC, it guarantees safe and efficient signal transmission. The contact mating area is also tin-plated for added durability, with a lifespan of 30 mating cycles. RoHS compliant and in stock for immediate shipment, this terminal is a dependable choice for wire-to-board connectors in various industries.
