39-29-9103

ICC Number:	MOL39-29-9103
Manufacturer:	Molex
Manufacturer Number:	39-29-9103
Datasheet:	Datasheet
ECAD Model:

Description:

Mini-Fit Jr. Vertical Header, 4.20mm Pitch, Dual Row, 10 Circuits, with Snap-in Plastic Peg PCB Lock, Tin, Natural

More >>

Specifications

Attribute	Value
Product Category:	PCB Connectors PCB Headers & Receptacles
Manufacturer:	Molex
Manufacturer Part Number:	Molex 39-29-9103
Gender:	Male
Number of Contacts:	10
Number of Rows:	2
Contact Material:	Brass
Contact Plating:	Tin
Pitch:	4.2 mm
Shroud Type:	Yes
Flammability Rating:	UL 94V-2
Current Rating:	9 A
Voltage Rating:	600 V
Operating Temperature:	-40 to 105 °C
Mounting Angle:	Straight
Mounting Type:	Through Hole
PCB Connector Type:	PCB Mount Header
SKU:	MOL39-29-9103

Detailed Description

39-29-9103 - Introducing the Mini-Fit Jr. Vertical Header, a versatile connectivity solution for your PCB needs. With a 4.20mm pitch and dual-row design, this header offers reliable performance in a compact form factor. Featuring 10 circuits and a snap-in plastic peg PCB lock, it ensures secure connections in your applications. The tin-plated brass contacts provide excellent conductivity, rated for up to 9A and 600V. Constructed with durable nylon housing, this header is suitable for a wide range of environments, with an operating temperature range of -40 to 105°C. RoHS compliant and lead-free process capable, it meets stringent environmental standards. Perfect for wire-to-board connections, this Mini-Fit Jr. header is a dependable choice for your projects.
