35362-0250

ICC Number:	MOL35362-0250
Manufacturer:	Molex
Manufacturer Number:	35362-0250
Datasheet:	Datasheet
ECAD Model:

Description:

2.00mm Pitch Sherlock Wire-to-Board Header, Vertical, with Positive Lock, 2 Circuits, with Kinked PC Tails, Natural

More >>

Specifications

Attribute	Value
Product Category:	PCB Connectors PCB Headers & Receptacles
Manufacturer:	Molex
Manufacturer Part Number:	Molex 35362-0250
Gender:	Male
Number of Contacts:	2
Number of Rows:	1
Contact Material:	Brass
Contact Plating:	Tin
Pitch:	2 mm
Shroud Type:	Yes
Flammability Rating:	UL 94V-0
Current Rating:	2 A
Voltage Rating:	125 V
Operating Temperature:	-40 to 105 °C
Mounting Angle:	Straight
Mounting Type:	Through Hole
PCB Connector Type:	Header
SKU:	MOL35362-0250

Detailed Description

Introducing the 35362-0250, a two-row straight through-hole connector from our Sherlock series. This high-quality connector, featuring a natural color, is crafted from durable nylon, ensuring reliable performance in a variety of applications. With a low amperage rating of 2A and a voltage capacity of 125V, it is suitable for use in many electronic devices. Tin-plated contact termination offers excellent conductivity, while its vertical orientation and 3.3mm tail length provide easy installation on a 1.6mm thick PCB. Certified by CSA and UL for safety and compliance, this connector is also RoHS certified, making it an environmentally friendly choice. Whether you're a professional in the field or a DIY enthusiast, the 35362-0250 is the perfect solution for your wire-to-board connection needs.

Frequently Bought Together

Product	Part #	Description	Stock
	Molex 22-01-3037	KK 254 Crimp Housing, Friction Ramp with Polarizing Ribs, 3 Circuits, Natural
	Molex 22-11-2022	KK 254 Solid Header, Vertical, with Friction Lock, 2 Circuits, 0.51µm Gold (Au) Plating, 3.56mm Tail Length
	Molex 22-11-2032	KK 254 Solid Header, Vertical, with Friction Lock, 3 Circuits, 0.51µm Gold (Au) Plating, 3.56mm Tail Length
	Molex 35362-0350	2.00mm Pitch Sherlock Wire-to-Board Header, Vertical, with Positive Lock, 3 Circuits, with Kinked PC Tails, Natural
	Molex 35362-0450	2.00mm Pitch Sherlock Wire-to-Board Header, Vertical, with Positive Lock, 4 Circuits, with Kinked PC Tails, Natural
	Molex 35362-0550	2.00mm Pitch Sherlock Wire-to-Board Header, Vertical, with Positive Lock, 5 Circuits, with Kinked PC Tails, Natural
	Molex 35362-0650	2.00mm Pitch Sherlock Wire-to-Board Header, Vertical, with Positive Lock, 6 Circuits, with Kinked PC Tails, Natural
	Molex 35362-1050	2.00mm Pitch Sherlock Wire-to-Board Header, Vertical, with Positive Lock, 10 Circuits, with Kinked PC Tails, Natural
	Molex 35363-0860	2.00mm Pitch Sherlock Wire-to-Board Header, Right-Angle, with Positive Lock, 8 Circuits
	Molex 39-00-0047	Mini-Fit Female Crimp Terminal, Tin (Sn) over Copper (Cu) Plated Brass, 28-22 AWG, Bag
	Molex 39-29-3066	Mini-Fit Jr. Vertical Header, 4.20mm Pitch, Dual Row, 6 Circuits, without Snap-in Plastic Peg PCB Lock, Tin, Natural
	Molex 39-29-3086	Mini-Fit Jr. Vertical Header, 4.20mm Pitch, Dual Row, 8 Circuits, without Snap-in Plastic Peg PCB Lock, Tin, Natural
	Molex 43045-1214	Micro-Fit 3.0 Vertical Header, 3.00mm Pitch, Dual Row, 12 Circuits, with PCB Polarizing Peg, 0.76µm Gold Plating, Glow-Wire Capable, Black
	Molex 501331-0607	1.00mm Pitch, Pico-Clasp PCB Header, Single Row, Vertical, Surface Mount, Tin Plated, Inner Positive Lock, 6 Circuits, Natural
	Molex 501331-0807	1.00mm Pitch, Pico-Clasp PCB Header, Single Row, Vertical, Surface Mount, Tin Plated, Inner Positive Lock, 8 Circuits, Natural
	Molex 53290-1080	2.00mm Pitch SlimStack Board-to-Board Header, Vertical, Single Row, 0.50mm Square Pin, with Friction Lock, 10 Circuits, with Kinked PC Tails
	Molex 79107-7003	Milli-Grid Vertical Receptacle, 2.00mm Pitch, Dual Row, Through Hole, 3.00mm Tail Length, 0.38µm Gold (Au) Plating, 8 Circuits, Lead-Free, Tube

Product Change Notice

Effective Date	Description of Change				Download
10/31/2017	503369 - Equipment Transfer, Production Transfer or Rearrangement. This letter is to inform you that production of the part(s) identified in this notice are being moved to a different production or shipping location. No changes will be made to the product as a result of this move.				Download
03/07/2016	GCN 10728004 - Supplier Change. The purpose of this letter is to inform you that a supplier of 0.5 diameter pin for 35362, 35363 and 104002 series will be changed to improve quality through vendor consolidation. The alternative supplier who produces various pins does business with both Molex Korea and other Molex plants as preferred supplier. There's no change in overall specification. The affected Molex product series are 35362, 35363 and 104002 series. These series are not affected by changing of pin supplier due to no risk. Implementation Date may be changed due to customer demand and production situation.				Download
