| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 22-03-2081 |
| Color: | Natural (White) |
| Series: | 4030 - KK 254 |
| Amperage: | 4 A |
| Connector Type: | KK 254 |
| Number of Contacts: | 8 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Body Orientation: | Straight |
| Pitch: | 2.54 mm |
| Voltage: | 500 V |
| Material: | Nylon |
| Orientation: | Vertical |
| Tail Length: | 3.43 mm |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | 5.08 µm |
| Number of Contacts Loaded: | 8 |
| Mating Cycles: | 25 |
| PCB Locator: | No |
| PCB Retention: | Without |
| Polarized to PCB: | No |
| Polarized to Mate: | No |
| PCB Thickness (Recommended): | 1.6 mm |
| Connector System: | Board to Board, Wire to Board |
| Contact Termination Plating: | Tin |
| Maximum Solder Process Temperature: | 235 °C |
| Lead Free Process Capability: | WAVE |
| Duration at Max. Process Temperature (seconds): | 005 |
| Max. Cycles at Max. Process Temperature: | 001 |
| Termination Pitch: | 2.54 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | No |
| Stackable: | Yes |
| Surface Mount Compatible: | No |
| Breakaway: | No |
| Shroud Type: | No |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0022032081 A-4030-08A197 |
| SKU: | MOL22-03-2081 |
22-03-2081
| Heilind Number: | MOL22-03-2081 |
| Manufacturer: | Molex |
| Manufacturer Number: | 22-03-2081 |
| Datasheet: | RoHS Certificate of Compliance |
| ECAD Model: | |
Description:
KK 254 Wire-to-Board Header, Single Row, Vertical, 8 Circuits, PA Polyamide Nylon, Tin (Sn) Plating
More >>Specifications
Detailed Description
Introducing the 22-03-2081 KK 254 Wire-to-Board Header, a crucial component for your electronic connections. This single-row header features 8 circuits, constructed with durable PA Polyamide Nylon and boasting Tin (Sn) Plating for enhanced conductivity. Its natural (White) color and straight body orientation make it versatile for various applications. With a pitch of 2.54 mm, it offers precise connectivity, handling up to 4 A of current and 500 V of voltage. Designed for through-hole termination, its brass contacts ensure reliable performance. RoHS compliant and with a high mating cycle of 25, this header guarantees long-lasting and environmentally friendly usage, perfect for your PCB connector needs. Available for immediate shipping.
