| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 19-09-2029 |
| Color: | Natural |
| Series: | 3191 |
| Amperage: | 12 A |
| Connector Type: | Standard .093" |
| Gender: | Plug |
| Housing Material: | Nylon |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| Pitch: | 6.7 mm |
| Material: | Nylon |
| Keying: | No |
| Operating Temperature Range: | -40 - 105 °C |
| Circuit Application: | Power |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Wire |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Breakaway: | No |
| Product Name: | Standard .093" |
| Material Flammability Standard: | 94V-2 |
| Part Aliases: | 0019092029 3191-2P1 |
| SKU: | MOL19-09-2029 |
19-09-2029
Specifications
Detailed Description
Introducing the Standard .093" Connector System, a reliable and versatile solution for your power circuit applications. This two-row housing features a durable nylon construction, meeting CSA and UL agency certifications for enhanced safety and performance. With a low operating temperature of -40°C and a high of 105°C, it ensures reliable operation in various environments. Each connector is polarized for error-free mating and includes a locking feature for added security. With two contacts and a 6.7mm pitch, it offers efficient wire-to-wire connection. RoHS compliant and in stock for immediate shipping, the Standard .093" Connector System is the perfect choice for your project.
