172708-0014
Mini-Fit TPA2 Receptacle Housing, 4.20mm Pitch, Dual Row, UL 94V-0, Low-Halogen, 14 Circuits
Part Aliases: Molex 1727080014
The Mini-Fit TPA2 Receptacle Housing in black is a versatile and reliable connector component designed for power applications. With a pitch of 4.20mm and featuring 14 circuits arranged in a dual row configuration, it offers efficient connectivity in various systems. Constructed from UL 94V-0 rated nylon, this housing ensures durability and safety even in demanding environments. Its low-halogen design further enhances its suitability for a wide range of applications. With operating temperatures ranging from -40 to 105 °C, it guarantees performance in both extreme cold and hot conditions. The connector is polarized to mate for easy and secure installation, with a locking feature for added stability. RoHS compliant and part of the Fit Families campaign, this product is not only environmentally friendly but also part of a larger system offering comprehensive connectivity solutions.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 172708-0014 |
| Color: | Black |
| Series: | 172708 - Mini-Fit TPA2 |
| Connector Type: | Mini-Fit TPA2 |
| Gender: | Receptacle |
| Number of Contacts: | 14 |
| Number of Rows: | 2 |
| Pitch: | 4.2 mm |
| Material: | Nylon |
| Operating Temperature Range: | -40 - 105 °C |
| Circuit Application: | Power |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Board, Wire to Wire |
| Termination Pitch: | 4.2 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Part Aliases: | 1727080014 |
| SKU: | MOL172708-0014 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
