| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 172185-0002 |
| Color: | Black |
| Series: | 172185 - EXTreme EnergetiC |
| Amperage: | 100 A |
| Connector Type: | EXTreme EnergetiC |
| Number of Contacts: | 29 |
| Number of Rows: | 5 |
| Termination Method: | Through Hole |
| Contact Material: | High Performance Alloy (HPA) |
| Body Orientation: | Right Angle |
| Pitch: | 2 mm, 7.65 mm |
| Voltage: | 600 V AC/DC |
| Material: | Liquid Crystal Polymer |
| Orientation: | Right Angle |
| Tail Length: | 2.71 mm, 2.74 mm |
| Packaging: | Tray |
| Operating Temperature Range: | -40 - 105 °C |
| Circuit Application: | Signal |
| Contact Mating Area Plating: | Gold over Nickel |
| Contact Mating Area Plating Thickness: | .762 µm |
| Number of Contacts Loaded: | 29 |
| Mating Cycles: | 200 |
| Polarized to PCB: | Yes |
| Contact Termination Plating Thickness: | 2.540 µm |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | 1.58 mm |
| Connector System: | Board to Board |
| CSA Agency Certification: | LR19980 |
| UL Agency Certification: | E29179 |
| Contact Termination Plating: | Tin over Nickel |
| Maximum Solder Process Temperature: | 260 °C |
| Lead Free Process Capability: | SMC and Wave |
| Duration at Max. Process Temperature (seconds): | 010 |
| Max. Cycles at Max. Process Temperature: | 003 |
| Power and Signal Configuration: | 25 s - 4 p |
| Glow Wire Capable: | No |
| Guide to Mating Part: | Yes |
| Surface Mount Compatible: | Yes |
| Breakaway: | No |
| Make First / Break Last: | No |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 1721850002 |
| SKU: | MOL172185-0002 |
172185-0002
Specifications
Detailed Description
Introducing the Molex EXTreme EnergetiC Modular Right-Angle Plug Assembly, featuring 29 circuits for high-performance connectivity. With 25 signal and 4 power contacts, this black plug assembly is designed for demanding applications. Constructed with a rugged Liquid Crystal Polymer body and High Performance Alloy contacts, it ensures reliable operation in harsh environments. The right-angle orientation and solder tail mounting offer versatility for installation. Rated for 100 A and 600 V AC/DC, it meets stringent safety standards. Gold over Nickel contact plating guarantees excellent conductivity, while tin over Nickel termination plating is ideal for lead-free processes. With UL and CSA certifications, this plug assembly is a trusted solution for your power and signal transmission needs.
