90119-0110
C-Grid III Crimp Terminal, 22-24 AWG, Reel, 0.38
Part Aliases: Molex 0901190110
The Molex C-Grid III Crimp Terminal, a high-quality connectivity solution designed for 22-24 AWG wires. This female terminal, with a tin contact plating on phosphor bronze, ensures reliable signal transmission in various circuit applications. Featuring a gold-plated contact mating area for enhanced durability, it allows for secure wire termination via crimp or compression methods. With a reel packaging for convenience, this terminal is suitable for automated assembly processes. RoHS compliant and with a wire insulation diameter of 1.02-1.47mm, it meets industry standards for environmental responsibility and performance. Upgrade your wire-to-board connections with the Molex C-Grid III Crimp Terminal.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 90119-0110 |
| Series: | 90119 - C-Grid III |
| Connector Type: | C-Grid III |
| Gender: | Female |
| Termination Method: | Crimp or Compression |
| Contact Material: | Phosphor Bronze |
| Contact Plating: | Tin |
| Circuit Application: | Signal |
| Contact Mating Area Plating: | Gold |
| Contact Mating Area Plating Thickness: | .381 µm |
| Contact Termination Plating Thickness: | 3.048 µm |
| Wire Size: | 22 AWG, 24 AWG |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | 1.02 - 1.47 mm |
| Part Aliases: | 0901190110 |
| SKU: | MOL90119-0110 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
