53261-0671

ICC Number:	MOL53261-0671
Manufacturer:	Molex
Manufacturer Number:	53261-0671
Datasheet:	Datasheet
ECAD Model:

Description:

1.25mm Pitch, PicoBlade PCB Header, Single Row, Right-Angle, Surface Mount, Tin (Sn) Plating, Friction Lock, 6 Circuits, Natural, Tape and Reel

More >>

Specifications

Attribute	Value
Product Category:	Uncategorized
Manufacturer:	Molex
Manufacturer Part Number:	Molex 53261-0671
Part Aliases:	0532610671
SKU:	MOL53261-0671

Detailed Description

Introducing the PicoBlade Connector System, a versatile solution for wire-to-board and wire-to-wire connections in electronic applications. This 1A connector features a compact right-angle design with 6 contacts, ideal for space-constrained PCB layouts. Constructed with high-temperature thermoplastic and tin-plated phosphor bronze contacts, it ensures reliable performance in harsh environments. With a pitch of 1.25mm and a voltage rating of 125V, it meets the demands of various low-power applications. Fully shrouded and polarized for secure mating, it offers easy installation and maintenance. RoHS compliant and with a mating cycle of 30, it guarantees longevity and environmental responsibility in usage. Upgrade your connectivity with the PicoBlade Connector System.
