| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 505570-0701 |
| Color: | Black |
| Series: | 505570 - Micro-Lock PLUS |
| Connector Type: | Micro-Lock PLUS |
| Gender: | Receptacle |
| Number of Contacts: | 7 |
| Number of Rows: | 1 |
| Pitch: | 2 mm |
| Material: | Polyester |
| Keying: | No |
| Operating Temperature Range: | -40 - 105 °C |
| Circuit Application: | Signal |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Board |
| Termination Pitch: | 2 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Part Aliases: | 5055700701 |
| SKU: | MOL505570-0701 |
505570-0701
Specifications
Detailed Description
Introducing the 505570-0701 Micro-Lock PLUS Receptacle Housing, a high-performance connector designed for signal applications. With a compact 2.00mm pitch and a single row configuration, this housing features 7 circuits for efficient connectivity. Crafted from durable black polyester, it ensures reliable operation in a wide temperature range from -40 to 105 °C. The integrated Positive Lock mechanism guarantees secure mating, while its polarized design prevents incorrect connections. Ideal for wire-to-board setups, this connector is RoHS compliant, making it a sustainable choice for various electronic devices. Upgrade your connectivity solutions with the Micro-Lock PLUS Receptacle Housing.
