48404-0003

MOL48404-0003
Heilind Number:MOL48404-0003
Manufacturer:Molex
Manufacturer Number:48404-0003
Datasheet:Drawing
ECAD Model:
3D Model

Description:

Universal Serial Bus (USB 3.0) I/O Receptacle, Upright 90

More >>

Specifications

AttributeValue
Product Category:
High Speed Connectors & Components High Speed Cage & Connector Assemblies
Manufacturer:Molex
Manufacturer Part Number:Molex 48404-0003
Color:Blue
Series:48404 - USB 3.0
Amperage:1.8 A
Connector Type:USB 3.0
Gender:Female
Number of Rows:2
Termination Method:Through Hole
Contact Material:Copper Alloy
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-20 °C
Pitch:2 mm, 2.5 mm
Voltage:30 V AC/DC
Material:Thermoplastic
Number of Ports:1
Orientation:Upright
Keying:Yes
USB Type:A
Component Type:Receptacle
Tail Length:2.4 mm
Packaging:Tray
Operating Temperature Range:-20 - 85 °C
Contact Mating Area Plating:Nickel, Tin
Ground to Panel / PCB:Yes
Number of Contacts Loaded:9
Mating Cycles:5000
PCB Locator:Yes
PCB Retention:Yes
Polarized to PCB:Yes
Polarized to Mate:Yes
Connector System:Wire to Board
Contact Termination Plating:Gold
Maximum Solder Process Temperature:255 °C
Lead Free Process Capability:REFLOW
Duration at Max. Process Temperature (seconds):005
Max. Cycles at Max. Process Temperature:001
Termination Pitch:2 mm, 2.5 mm
Lock to Mating Part:No
Part Aliases:0484040003
SKU:MOL48404-0003

Detailed Description

Introducing the 48404-0003, a high-speed USB 3.0 I/O Receptacle designed for universal connectivity. Featuring an upright 90-degree orientation and a vibrant blue color, this female connector is both visually striking and versatile. With two rows of contacts and a through-hole termination method, it ensures secure and reliable connections on PCBs. Constructed with a durable thermoplastic housing and copper alloy contacts plated with nickel and tin, it guarantees longevity and excellent signal transmission. Rated for 1.8A and 30V AC/DC, it offers high performance in a wide temperature range from -20 to 85°C. RoHS compliant and lead-free reflow solder process compatible, it meets international standards for environmental responsibility. Perfect for a variety of applications, the 48404-0003 is a top choice for high-speed data transfer and connectivity needs.
