| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 43650-0202 |
| Color: | Black |
| Series: | 43650 |
| Amperage: | 8.5 A |
| Connector Type: | Micro-Fit 3.0 |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Body Orientation: | Right Angle |
| Pitch: | 3 mm |
| Voltage: | 600 V |
| Material: | High Temperature Thermoplastic |
| Orientation: | Right Angle |
| Operating Temperature Range: | -40 - 105 °C |
| Contact Mating Area Plating: | Gold |
| Contact Mating Area Plating Thickness: | .762 µm |
| Number of Contacts Loaded: | 2 |
| Mating Cycles: | 30 |
| PCB Locator: | Yes |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| Contact Termination Plating Thickness: | 2.540 µm |
| PCB Thickness (Recommended): | 1.6 mm |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin |
| Maximum Solder Process Temperature: | 260 °C |
| Lead Free Process Capability: | SMC and Wave |
| Duration at Max. Process Temperature (seconds): | 030 |
| Max. Cycles at Max. Process Temperature: | 003 |
| Glow Wire Capable: | Yes |
| Mated Height: | 6.98 mm |
| Stackable: | No |
| Surface Mount Compatible: | Yes |
| Breakaway: | No |
| Shroud Type: | Fully |
| Product Name: | Micro-Fit 3.0 |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0436500202 |
| SKU: | MOL43650-0202 |
43650-0202
| Heilind Number: | MOL43650-0202 |
| Manufacturer: | Molex |
| Manufacturer Number: | 43650-0202 |
| Datasheet: | Packaging Specifications |
| ECAD Model: | |
Description:
Micro-Fit 3.0 Right-Angle Header, 3.00mm Pitch, Single Row, 2 Circuits, with Snap-in Plastic Peg PCB Lock, Gold, Glow-Wire Capable, Black
More >>Specifications
Detailed Description
Introducing the 43650-0202, a Micro-Fit 3.0 Right-Angle Header designed for optimal performance in electronic connections. With a 3.00mm pitch and featuring a single row with 2 circuits, this header is equipped with a snap-in plastic peg PCB lock for secure attachment. Its gold glow-wire capable contact mating area plating ensures reliable conductivity, while its black high temperature thermoplastic construction guarantees durability in harsh operating environments. With a voltage rating of 600V and an amperage of 8.5A, this connector is suitable for a wide range of applications. RoHS compliant and lead-free process capable, the Micro-Fit 3.0 header meets stringent environmental standards, making it the ideal choice for your connectivity needs.
