| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 39920-0302 |
| Color: | Black |
| Series: | 39920 - Eurostyle Fixed Mount |
| Amperage: | 115 A |
| Connector Type: | Eurostyle Fixed Mount |
| Number of Rows: | 1 |
| Mount Type: | No |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Body Orientation: | Straight |
| Pitch: | 15 mm |
| Voltage: | 600 V |
| Material: | Polyester |
| Orientation: | Vertical |
| Block Type: | Shrouded |
| Component Type: | One Piece |
| Tail Length: | 6.35 mm |
| Operating Temperature Range: | 130 °C |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | 3.81 µm |
| Number of Contacts Loaded: | 2 |
| PCB Retention: | Yes |
| Contact Termination Plating Thickness: | 3.81 µm |
| Polarized to Mate: | Yes |
| Wire Size: | 10 - 35 mm², 1 AWG, 2 AWG, 3 AWG, 4 AWG, 6 AWG, 8 AWG |
| UL Agency Certification: | E48521 |
| Contact Termination Plating: | Tin |
| Lead Free Process Capability: | WAVE |
| Termination Pitch: | 15 mm |
| Lock to Mating Part: | No |
| Stackable: | No |
| Surface Mount Compatible: | No |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0399200302 92B0502 |
| SKU: | MOL39920-0302 |
39920-0302
| Heilind Number: | MOL39920-0302 |
| Manufacturer: | Molex |
| Manufacturer Number: | 39920-0302 |
| Datasheet: | RoHS Certificate of Compliance |
| ECAD Model: | |
Description:
15.00mm Beau Eurostyle, Fixed Mount PCB Terminal Block, High Voltage, High Power 115A, 2 Circuits
More >>Specifications
Detailed Description
Introducing the 39920-0302, a high-performance Eurostyle Fixed Mount terminal block designed for robust electrical connections. With a black polyester body and shrouded one-piece construction, this terminal block ensures durability and safety in various applications. Featuring a straight body orientation and through-hole termination method, it offers easy and secure installation on PCBs. Rated for 115A and 600V, with brass contacts plated in tin, it guarantees reliable conductivity even in demanding environments. UL certified and RoHS compliant, this terminal block meets stringent quality and environmental standards. Perfect for wire sizes ranging from 8 AWG to 2 AWG (10-35 mm²), it is ideal for power and signal connections in industrial and commercial settings. Upgrade to the 39920-0302 for efficient and dependable terminal block solutions.
