39-29-9102

Heilind Number:	MOL39-29-9102
Manufacturer:	Molex
Manufacturer Number:	39-29-9102
Datasheet:	Packaging Specifications
ECAD Model:

Description:

Mini-Fit Jr. Vertical Header, 4.20mm Pitch, Dual Row, 10 Circuits, with Snap-in Plastic Peg PCB Lock, Tin, Natural

More >>

Specifications

Attribute	Value
Product Category:	PC Board Pin & Receptacle Connectors PCB Pin Headers
Manufacturer:	Molex
Manufacturer Part Number:	Molex 39-29-9102
Color:	Natural
Series:	5566 - Mini-Fit Jr.
Amperage:	9 A
Connector Type:	Mini-Fit Jr.
Number of Contacts:	10
Number of Rows:	2
Termination Method:	Through Hole
Contact Material:	Brass
Body Orientation:	Straight
Pitch:	4.2 mm
Voltage:	600 V
Material:	Nylon
Orientation:	Vertical
Keying:	No
Tail Length:	3.5 mm
Operating Temperature Range:	-40 - 105 °C
Contact Mating Area Plating:	Tin
Contact Mating Area Plating Thickness:	.889 µm
Number of Contacts Loaded:	10
Mating Cycles:	30
PCB Locator:	Yes
PCB Retention:	Yes
Polarized to PCB:	Yes
Contact Termination Plating Thickness:	.889 µm
Polarized to Mate:	Yes
PCB Thickness (Recommended):	1.6 mm
Connector System:	Wire to Board
Contact Termination Plating:	Tin
Maximum Solder Process Temperature:	240 °C
Lead Free Process Capability:	WAVE
Duration at Max. Process Temperature (seconds):	005
Max. Cycles at Max. Process Temperature:	001
Termination Pitch:	4.2 mm
Glow Wire Capable:	No
Guide to Mating Part:	No
Lock to Mating Part:	Yes
Stackable:	No
Surface Mount Compatible:	No
Breakaway:	No
Make First / Break Last:	No
Shroud Type:	Fully
Material Flammability Standard:	94V-2
Part Aliases:	0039299102 5566-10B2
SKU:	MOL39-29-9102

Detailed Description

Introducing the Molex Mini-Fit Jr. Vertical Header, a reliable and high-performance PCB connector designed for a variety of applications. With a compact 4.20mm pitch and dual-row configuration, this header accommodates 10 circuits, offering ample connectivity in a space-efficient manner. Featuring a snap-in plastic peg PCB lock, installation is secure and hassle-free. The tin-plated brass contacts ensure excellent conductivity, with a current rating of 9A and a voltage of 600V. Constructed from durable nylon, this connector is suitable for a wide operating temperature range of -40 to 105 °C. RoHS compliant and lead-free process capable, it meets stringent environmental standards. Perfect for wire-to-board connections, this Mini-Fit Jr. header is a dependable choice for your electronic projects.
