| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 33011-3002 |
| Series: | 33011 - MX150 |
| Connector Type: | MX150 |
| Gender: | Male |
| Termination Method: | Crimp or Compression |
| Contact Material: | High Performance Alloy (HPA) |
| Contact Plating: | Silver |
| Voltage: | 14 V DC |
| Circuit Application: | Power |
| Contact Mating Area Plating: | Silver |
| Contact Mating Area Plating Thickness: | .762 µm |
| Contact Termination Plating Thickness: | 2.540 µm |
| Wire Size: | 16 AWG, 18 AWG, 20 AWG, .75 - 1 mm² |
| Connector System: | Wire to Board, Wire to Wire |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | 2.54 mm |
| Part Aliases: | 0330113002 |
| SKU: | MOL33011-3002 |
33011-3002
| Heilind Number: | MOL33011-3002 |
| Manufacturer: | Molex |
| Manufacturer Number: | 33011-3002 |
| Datasheet: | Product Specification |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the 33011-3002 MX150 Male Terminal, a high-performance solution for your automotive connectivity needs. This terminal, featuring durable silver plating, is designed for 16, 18, and 20 AWG wires, ensuring secure and reliable connections in power applications up to 14 V DC. With a left reel payoff design, it facilitates efficient assembly processes. The contact material, a High Performance Alloy (HPA), combined with silver plating, guarantees excellent conductivity and corrosion resistance. Suitable for both crimp and compression terminations, this terminal accommodates versatile installation methods. Its tin-plated termination offers added durability. RoHS compliant and in stock for immediate shipping, the MX150 Male Terminal is a dependable choice for wire-to-wire and wire-to-board connections in automotive environments.
