| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 26-48-1105 |
| Color: | Black |
| Series: | 41671 - KK 396 |
| Amperage: | 7 A |
| Connector Type: | KK 396 |
| Number of Contacts: | 10 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Body Orientation: | Straight |
| Pitch: | 3.96 mm |
| Voltage: | 250 V |
| Material: | Polyester |
| Orientation: | Vertical |
| Tail Length: | 4.37 mm |
| Packaging: | Bag |
| Contact Mating Area Plating: | Tin |
| Number of Contacts Loaded: | 10 |
| Mating Cycles: | 25 |
| PCB Locator: | No |
| PCB Retention: | Without |
| Polarized to PCB: | No |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | 1.6 mm |
| Connector System: | Wire to Board |
| CSA Agency Certification: | LR19980 |
| UL Agency Certification: | E29179 |
| Maximum Solder Process Temperature: | 235 °C |
| Lead Free Process Capability: | WAVE |
| Duration at Max. Process Temperature (seconds): | 005 |
| Max. Cycles at Max. Process Temperature: | 001 |
| Termination Pitch: | 3.96 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Breakaway: | Yes |
| Shroud Type: | Partial |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0026481105 A-41671-C10A197 |
| SKU: | MOL26-48-1105 |
26-48-1105
| Heilind Number: | MOL26-48-1105 |
| Manufacturer: | Molex |
| Manufacturer Number: | 26-48-1105 |
| Datasheet: | RoHS Certificate of Compliance |
| ECAD Model: | |
Description:
KK 396 Breakaway Header, Vertical, Square Pin, with Friction Lock, 10 Circuits, Tin (Sn) Plating
More >>Specifications
Detailed Description
Introducing the 26-48-1105 KK 396 Breakaway Header, a versatile vertical connector with 10 circuits for seamless PCB integration. Featuring square pin contacts with friction lock and durable tin plating, this black header ensures reliable signal transmission in a variety of applications. With a low amperage rating of 7A and a voltage capacity of 250V, it guarantees safe and efficient performance. Constructed with high-quality brass contacts and a polyester housing, it offers excellent durability. UL and CSA certified, this connector is suitable for use in a wide range of industries. Its straight body orientation and through-hole termination method make installation easy and secure. RoHS compliant and lead-free solder capable, it meets environmental standards. Perfect for wire-to-board connections, the KK 396 Breakaway Header is a dependable solution for your connectivity needs.
