22-23-2051

ICC Number:	MOL22-23-2051
Manufacturer:	Molex
Manufacturer Number:	22-23-2051
Datasheet:	Datasheet
ECAD Model:

Description:

KK 254 Solid Header, Vertical, with Friction Lock, 5 Circuits, 2.54µm Matte Tin (Sn) Plating, 3.56mm Tail Length

More >>

Specifications

Attribute	Value
Product Category:	PCB Connectors PCB Headers & Receptacles
Manufacturer:	Molex
Manufacturer Part Number:	Molex 22-23-2051
Gender:	Male
Number of Contacts:	5
Number of Rows:	1
Contact Material:	Brass
Contact Plating:	Tin
Pitch:	2.54 mm
Shroud Type:	Yes
Flammability Rating:	UL 94V-0
Current Rating:	4 A
Voltage Rating:	500 V
Operating Temperature:	-40 to 80 °C
Mounting Angle:	Straight
Mounting Type:	Through Hole
PCB Connector Type:	PCB Mount Header
SKU:	MOL22-23-2051

Detailed Description

Introducing the 22-23-2051 KK 254 Solid Header, a vertical connector with friction lock designed for reliable performance. With 5 circuits and tin (Sn) plating, this header ensures efficient connectivity in various applications. Its natural (white) color and straight body orientation offer versatility in PCB designs. Constructed with brass contacts and nylon material, it guarantees durability and a maximum voltage of 500 V. UL and CSA agency certifications validate its quality and safety standards. Ideal for wire-to-board connections, this header is RoHS compliant and suitable for lead-free soldering processes, making it a dependable choice for your electronic projects.
