| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 22-03-2061 |
| Color: | Natural (White) |
| Series: | 4030 - KK 254 |
| Amperage: | 4 A |
| Connector Type: | KK 254 |
| Number of Contacts: | 6 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Body Orientation: | Straight |
| Pitch: | 2.54 mm |
| Voltage: | 500 V |
| Material: | Nylon |
| Orientation: | Vertical |
| Tail Length: | 3.43 mm |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | 5.08 µm |
| Number of Contacts Loaded: | 6 |
| Mating Cycles: | 25 |
| PCB Locator: | No |
| PCB Retention: | Without |
| Polarized to PCB: | No |
| Polarized to Mate: | No |
| PCB Thickness (Recommended): | 1.6 mm |
| Connector System: | Board to Board, Wire to Board |
| Contact Termination Plating: | Tin |
| Maximum Solder Process Temperature: | 235 °C |
| Lead Free Process Capability: | WAVE |
| Duration at Max. Process Temperature (seconds): | 005 |
| Max. Cycles at Max. Process Temperature: | 001 |
| Termination Pitch: | 2.54 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | No |
| Stackable: | Yes |
| Surface Mount Compatible: | No |
| Breakaway: | No |
| Shroud Type: | No |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0022032061 A-4030-06A197 |
| SKU: | MOL22-03-2061 |
22-03-2061
Specifications
Detailed Description
Introducing the 22-03-2061 KK 254 Wire-to-Board Header, a versatile connectivity solution for your electronic projects. This single-row header features a vertical orientation and 6 circuits, making it ideal for space-saving applications. Constructed with durable PA Polyamide Nylon and featuring Tin (Sn) plating, this header ensures reliable performance. The natural (white) color adds a sleek touch to your PCB design. With a low amperage rating of 4 A, it is suitable for a variety of low-power applications. Each header is equipped with brass contacts and offers through-hole termination for easy installation. Meeting strict quality standards, including RoHS compliance, this header guarantees safety and reliability in your designs. Upgrade your PCB connectivity with the 22-03-2061 KK 254 Wire-to-Board Header.
