| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 19164-0055 |
| Color: | Blue |
| Series: | 19164 - Perma-Seal |
| Connector Type: | Perma-Seal, Snap Receptacle |
| Gender: | Female |
| Termination Method: | Crimp or Compression |
| Contact Material: | Brass |
| Contact Plating: | Tin |
| Voltage: | 600 V |
| Material: | Brass, Nylon |
| Insulation Material: | NiAc |
| Orientation: | Straight |
| Insulation Type: | Partial |
| Operating Temperature Range: | -55 - 125 °C |
| Contact Mating Area Plating: | Tin |
| Wire Size: | 14 AWG, 16 AWG, 1 - 2.5 mm² |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | 3.81 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | No |
| Part Aliases: | 0191640055 SBRB-8180N |
| SKU: | MOL19164-0055 |
19164-0055
| Heilind Number: | MOL19164-0055 |
| Manufacturer: | Molex |
| Manufacturer Number: | 19164-0055 |
| Datasheet: | RoHS Certificate of Compliance |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the 19164-0055, a high-quality Perma-Seal Snap Receptacle designed for 14-16 AWG wires. With a durable brass construction and tin plating, this female connector ensures reliable and secure connections in a variety of applications. Its crimp or compression termination method allows for easy installation, while its nylon and NiAc insulation materials provide excellent protection. Operating at temperatures ranging from -55 to 125 °C and rated for up to 600 V, this connector is both robust and versatile. RoHS compliant and in stock for immediate shipping, it is the perfect choice for your connectivity needs.
