| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 173113-0058 |
| Gender: | Male |
| Housing Material: | Steel |
| Number of Contacts: | 15 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold Over Nickel |
| Insulation Material: | Polybutylene Terephthalate |
| Shielded: | Yes |
| Wire Size: | 22 AWG |
| Current Rating: | 3 A |
| D-Sub Shell Size: | S1 |
| Operating Temperature: | -55 to 105 °C |
| Mounting Angle: | Straight |
| Mounting Type: | Panel Mount |
| D-Sub Connector Type: | High Density |
| SKU: | MOL173113-0058 |
173113-0058
| ICC Number: | MOL173113-0058 |
| Manufacturer: | Molex |
| Manufacturer Number: | 173113-0058 |
| ECAD Model: | |
Description:
FCT High-Density D-Sub Connector, Male, Straight, Solder Cup, Gold Plating, 15 Circuits
More >>Specifications
Detailed Description
Introducing the FCT High-Density D-Sub Connector, Male, Straight, featuring a durable Steel shell with Nickel plating for enhanced longevity. This versatile connector accommodates 15 Circuits with a solder cup termination method, making it ideal for high-density applications. Crafted from a Copper Alloy base material and plated with Gold over Nickel, it ensures reliable conductivity and corrosion resistance. With an IP20 rating, it offers protection against solid objects and is suitable for various environments. RoHS compliant and designed for 22 AWG wire size, this connector is a dependable choice for your connectivity needs. Available under SKU 173113-0058, it is part of the FCT Products series, catering to the Power Connectors segment.
