173109-0075
HPD Standard-Density D-Sub Connector, Straight, PCB, Through Hole, with Machined Male Contacts, Panel Mount, 9 Circuits
Part Aliases: Molex 1731090075 Molex F09P1G1-0982
The HPD Standard-Density D-Sub Connector, a high-performance solution for your connectivity needs. This male connector features a straight orientation for seamless integration into your PCB through a 1.6mm panel mount. With 9 circuits and two rows, it ensures reliable data transmission, supported by machined male contacts with gold over nickel plating. Operating efficiently in a wide temperature range from -55 to 130°C, this connector is durable and dependable. Its IP20 rating guarantees protection against solid objects, making it suitable for various environments. With RoHS compliance and 500 mating cycles, the HPD Connector offers longevity and sustainability, perfect for your power connector requirements.
Details
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 173109-0075 |
| Series: | 173109 |
| Amperage: | 7.5 A |
| Gender: | Male |
| Number of Contacts: | 9 |
| Number of Rows: | 2 |
| Termination Method: | Through Hole |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold Over Nickel |
| Pitch: | 2.84 mm |
| IP Rating: | IP20 |
| Number of Ports: | 1 |
| Orientation: | Straight |
| Insert Material: | Thermoplastic |
| Frame Material: | Tin-plated Steel |
| Panel Thickness: | 1.6 mm |
| Tail Length: | 10.3 mm |
| Operating Temperature Range: | -55 - 130 °C |
| Contact Mating Area Plating: | Gold over Nickel |
| Contact Mating Area Plating Thickness: | .8 µm |
| Number of Contacts Loaded: | 9 |
| Mating Cycles: | 500 |
| Panel Mount Method: | Flange |
| PCB Locator: | Yes |
| Shielded: | Yes |
| Insert Color: | White |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| Type: | Standard Density |
| Mating Pitch: | 2.84 mm |
| Contact Termination Plating Thickness: | .8 µm |
| Polarized to Mate: | Yes |
| Product Name: | FCT Products |
| Part Aliases: | 1731090075 F09P1G1-0982 |
| SKU: | MOL173109-0075 |
Frequently bought together
Compliance
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
