173109-0074
HPD Standard-Density D-Sub Connector, Straight, PCB, Through Hole, with Machined Female Contacts, Panel Mount, 9 Circuits
Part Aliases: Molex 1731090074 Molex F09S1G1-0982
The HPD Standard-Density D-Sub Connector, a reliable and high-performance solution for your connectivity needs. This female connector features 9 circuits in a straight, through-hole design, with machined female contacts for superior conductivity. Panel mountable with a 2.84mm pitch, it is perfect for PCB applications. Constructed with a thermoplastic insert and tin-plated steel frame, this connector ensures durability in harsh environments. With a gold over nickel contact plating and IP20 rating, it guarantees secure and stable connections. RoHS compliant and rated for 500 mating cycles, the HPD connector is a trusted choice for power and signal transmission in various industries.
Details
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 173109-0074 |
| Series: | 173109 |
| Amperage: | 7.5 A |
| Gender: | Female |
| Number of Contacts: | 9 |
| Number of Rows: | 2 |
| Termination Method: | Through Hole |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold Over Nickel |
| Pitch: | 2.84 mm |
| IP Rating: | IP20 |
| Number of Ports: | 1 |
| Orientation: | Straight |
| Insert Material: | Thermoplastic |
| Frame Material: | Tin-plated Steel |
| Panel Thickness: | 1.6 mm |
| Tail Length: | 10.3 mm |
| Operating Temperature Range: | -55 - 130 °C |
| Contact Mating Area Plating: | Gold over Nickel |
| Contact Mating Area Plating Thickness: | .8 µm |
| Number of Contacts Loaded: | 9 |
| Mating Cycles: | 500 |
| Panel Mount Method: | Flange |
| PCB Locator: | Yes |
| Shielded: | Yes |
| Insert Color: | White |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| Type: | Standard Density |
| Mating Pitch: | 2.84 mm |
| Contact Termination Plating Thickness: | .8 µm |
| Polarized to Mate: | Yes |
| Product Name: | FCT Products |
| Part Aliases: | 1731090074 F09S1G1-0982 |
| SKU: | MOL173109-0074 |
Frequently bought together
Compliance
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
