| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 172718-5121 |
| Series: | 172718 - Mini-Fit TPA2 |
| Amperage: | 11.5 A |
| Connector Type: | Mini-Fit TPA2 |
| Gender: | Female |
| Termination Method: | Crimp or Compression |
| Contact Material: | Brass |
| Contact Plating: | Tin |
| Voltage: | 600 V AC/DC |
| Circuit Application: | Power |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | 2.5 µm |
| Mating Cycles: | 30 |
| Contact Termination Plating Thickness: | 2.5 µm |
| Wire Size: | 22 AWG, 24 AWG |
| Connector System: | Wire to Board, Wire to Wire |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | 1.07 - 1.65 mm |
| Part Aliases: | 1727185121 |
| SKU: | MOL172718-5121 |
172718-5121
Specifications
Detailed Description
Introducing the Molex Mini-Fit TPA2 Female Crimp Terminal, a reliable and high-performance connectivity solution for your power applications. Constructed with brass and featuring pre-plated tin for enhanced durability, this terminal is designed for 22-24 AWG wires with an insulation diameter of 1.07-1.65mm. It is suitable for both wire-to-wire and wire-to-board connections, offering versatility in your projects. With a current rating of 11.5 A and a voltage capacity of 600 V AC/DC, it ensures efficient power transmission. The tin-plated contact mating area guarantees low contact resistance, while the 2.5 µm plating thickness enhances longevity. RoHS compliant and available for immediate shipping, the Mini-Fit TPA2 terminal is the perfect choice for your high-reliability applications.
