172708-0012

Heilind Number:	MOL172708-0012
Manufacturer:	Molex
Manufacturer Number:	172708-0012
Datasheet:	Datasheet
ECAD Model:

Description:

Mini-Fit TPA2 Receptacle Housing, 4.20mm Pitch, Dual Row, UL 94V-0, Low-Halogen, 12 Circuits

More >>

Specifications

Attribute	Value
Product Category:	Pin & Socket Housings & Contacts Pin & Socket Housings
Manufacturer:	Molex
Manufacturer Part Number:	Molex 172708-0012
Color:	Black
Series:	172708 - Mini-Fit TPA2
Connector Type:	Mini-Fit TPA2
Gender:	Receptacle
Housing Material:	Nylon
Number of Contacts:	12
Number of Rows:	2
Pitch:	4.2 mm
Material:	Nylon
Operating Temperature Range:	-40 - 105 °C
Circuit Application:	Power
Polarized to Mate:	Yes
Connector System:	Wire to Board, Wire to Wire
Termination Pitch:	4.2 mm
Glow Wire Capable:	No
Lock to Mating Part:	Yes
Stackable:	No
Material Flammability Standard:	94V-0
Part Aliases:	1727080012
SKU:	MOL172708-0012

Detailed Description

Introducing the 172708-0012 Mini-Fit TPA2 Receptacle Housing, a high-performance connectivity solution designed for power applications. This black housing, constructed from UL 94V-0 rated nylon, features 12 circuits arranged in a dual row configuration with a pitch of 4.2mm. Engineered for durability, it is both low-halogen and RoHS compliant, ensuring environmental responsibility. With operating temperatures ranging from -40 to 105°C, it is suitable for a variety of industrial settings. Its polarized design and locking feature guarantee secure connections, while its versatility allows for wire-to-wire or wire-to-board installation. Part of the Fit Families campaign, this housing offers reliable performance for your connectivity needs.
