| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 172704-0003 |
| Series: | 172704 |
| Amperage: | 7.5 A |
| Gender: | Male |
| Number of Contacts: | 25 |
| Number of Rows: | 2 |
| IP Rating: | IP20 |
| Number of Ports: | 1 |
| Insert Material: | Thermoplastic |
| Frame Material: | Tin-plated Steel |
| Operating Temperature Range: | -55 - 130 °C |
| Mating Cycles: | 500 |
| Panel Mount Method: | Flange |
| Shielded: | Yes |
| Insert Color: | Black |
| Type: | Standard Density |
| Polarized to Mate: | Yes |
| Product Name: | FCT Products |
| Part Aliases: | 1727040003 FL25P7-K120 |
| SKU: | MOL172704-0003 |
172704-0003
| Heilind Number: | MOL172704-0003 |
| Manufacturer: | Molex |
| Manufacturer Number: | 172704-0003 |
| Datasheet: | Product Literature |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the HPD Standard-Density D-Sub Plug Housing, a reliable solution for your connectivity needs. This male Crimp housing, designed for Panel Mount installation, features 25 Circuits arranged in 2 rows. With an Amperage rating of 7.5 A and IP20 Ingress Protection, it ensures safe and efficient operation in various environments. Crafted from Thermoplastic insert material and Tin-plated Steel frame, this housing guarantees durability and longevity, even in harsh conditions. Its black insert color, along with being RoHS compliant, makes it suitable for a wide range of applications. Each unit is polarized to mate, preventing incorrect connections. Trust in the FCT Products 1727040003 for high-performance connectivity in your projects.
