172704-0010
HPD Standard-Density D-Sub Receptacle Housing, Crimp, Panel Mount, 9 Circuits
Part Aliases: Molex 1727040010 Molex FL09S7-K121
The HPD Standard-Density D-Sub Receptacle Housing, a reliable and high-performance connectivity solution for your electronic devices. This female connector features a crimp design for secure wire attachment, along with panel mount capabilities for easy installation. With 9 circuits arranged in 2 rows, it offers ample connectivity options. Rated for 7.5 A and featuring a tin-plated steel frame, this connector ensures durability and excellent conductivity. Its IP20 rating guarantees protection against dust and debris, while the black thermoplastic insert adds to its robust construction. Designed for polarized mating, it provides error-free connections in a wide range of applications. RoHS compliant and with 500 mating cycles, the HPD connector is a dependable choice for your connectivity needs.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 172704-0010 |
| Series: | 172704 |
| Amperage: | 7.5 A |
| Gender: | Female |
| Number of Contacts: | 9 |
| Number of Rows: | 2 |
| IP Rating: | IP20 |
| Number of Ports: | 1 |
| Insert Material: | Thermoplastic |
| Frame Material: | Tin-plated Steel |
| Operating Temperature Range: | -55 - 130 °C |
| Mating Cycles: | 500 |
| Panel Mount Method: | Flange |
| Shielded: | Yes |
| Insert Color: | Black |
| Type: | Standard Density |
| Polarized to Mate: | Yes |
| Product Name: | FCT Products |
| Part Aliases: | 1727040010 FL09S7-K121 |
| SKU: | MOL172704-0010 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
Product Change Notice
| Effective Date | Description of Change | Download |
|---|---|---|
| 02/15/2016 | FCT20160215 - FCT To Molex Part Numbers. | Download |
