FX8C-140P-SV1(91)

HIRFX8C-140P-SV1(91)
Heilind Number:HIRFX8C-140P-SV1(91)
Manufacturer:Hirose
Manufacturer Number:FX8C-140P-SV1(91)
ECAD Model:
3D Model

Description:

578-0527-2-91 EACH

More >>

Specifications

AttributeValue
Product Category:
Board To Board PCB Connectors Mezzanine & Board Stacking Connectors
Manufacturer:Hirose
Manufacturer Part Number:Hirose FX8C-140P-SV1(91)
Color:Beige
Series:FX8C
Gender:Male
Housing Material:Polyphenylene Sulfide
Number of Contacts:140
Number of Rows:2
Mount Type:Surface Mount
Termination Method:Solder
Contact Material:Phosphor Bronze
Contact Plating:Gold
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-55 °C
Pitch:0.6 mm
Mount Angle:Straight
Mating Cycles:50 cycle
Flammability Rating:UL 94V-0
Current Rating:0.4 A
Voltage Rating:100 VAC
SKU:HIRFX8C-140P-SV1(91)

Detailed Description

Introducing the FX8C-140P-SV1(91), a high-performance beige male connector from the FX8C series. Engineered for durability, it features a housing made of polyphenylene sulfide and phosphor bronze contacts with gold plating, ensuring reliable signal transmission. With 140 contacts arranged in 2 rows and a surface mount design, this connector offers efficient PCB connectivity. Rated for a wide operating temperature range of -55°C to 85°C and 100 VAC, it is suitable for diverse applications. Its low 0.6mm pitch and straight mount angle allow for space-saving installation. Certified for RoHS compliance and UL 94V-0 flammability rating, this connector guarantees safety and environmental responsibility. Perfect for board-to-board and mezzanine connections, the FX8C140PSV191 is a versatile and dependable solution for your connectivity needs.
