DF60A-2S-10.16C
680-3059-0-00 BAG
The DF60A-2S-10.16C, a high-performance female connector designed for reliable PCB mounting. With two contacts arranged in a single row, this connector offers seamless connectivity in various electronic applications. Crafted from durable Polybutylene Terephthalate, it ensures long-lasting performance even in demanding environments. Featuring a convenient crimp termination method and a wide operating temperature range from -55°C to 105°C, it guarantees secure and stable connections. The 10.16mm pitch and straight mount angle, along with a voltage rating of 1000V, make it suitable for high-power applications. With UL 94V-0 flammability rating and RoHS compliance, rest assured of its safety and environmental responsibility. Upgrade your connectivity with the DF60 series connector.
Details
| Product Category: | |
| Manufacturer: | Hirose |
| Manufacturer Part Number: | Hirose DF60A-2S-10.16C |
| Series: | DF60 |
| Gender: | Female |
| Housing Material: | Polybutylene Terephthalate |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| Mount Type: | PCB Mount |
| Termination Method: | Crimp |
| Maximum Operating Temperature: | 105 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 10.16 mm |
| Mating Type: | Latch |
| Mount Angle: | Straight |
| Contact Resistance: | 2 mΩ |
| Housing Color: | Black |
| Insulation Resistance: | 1000 mOhm |
| Mating Cycles: | 30 cycle |
| Wire Size: | 12 - 8 AWG |
| Flammability Rating: | UL 94V-0 |
| Voltage Rating: | 1000 V |
| SKU: | HIRDF60A-2S-10.16C |
Frequently bought together
Compliance
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
