804-112

Heilind Number:	WAG804-112
Manufacturer:	WAGO
Manufacturer Number:	804-112
ECAD Model:

Description:

MOD PCB CONN 12-POS CCS

More >>

Specifications

Attribute	Value
Product Category:	Terminal Blocks PCB Mount Terminal Blocks
Manufacturer:	WAGO
Manufacturer Part Number:	WAGO 804-112
Pitch:	5 mm
Series:	804
Wire Size:	20 - 12 AWG
Mount Type:	Through Hole
Housing Color:	Gray
Conductor Size:	20 - 12 AWG
Current Rating:	24 A
Voltage Rating:	630 V
Contact Plating:	Tin
Number of Poles:	12
Contact Material:	Electrolytic Copper
Housing Material:	Nylon
Number of Levels:	1
Termination Method:	Push-In
Flammability Rating:	UL 94V-0
Part Aliases:	51131953
SKU:	WAG804-112

Detailed Description

The 804-112 is a high-performance 12-position CCS modular PCB connector, designed for efficient and reliable power and signal transmission in electronic applications. Featuring a durable nylon housing and through-hole mount type, this connector ensures secure installation and robust connectivity. The push-in termination method, along with electrolytic copper contacts plated with tin, guarantees low contact resistance and enhanced conductivity. With a pitch of 5mm and a current rating of 24A at 630V, it accommodates heavy-duty power requirements. Its UL 94V-0 flammability rating and RoHS compliance ensure safety and environmental responsibility. Suitable for 20-12 AWG wire sizes, this connector is ideal for a wide range of industrial and commercial applications.
