804-102
MOD PCB CONN 2-POS CCS
Part Aliases: WAGO 51131922
The 804-102, a high-performance MOD PCB CONN 2-POS CCS designed for seamless connectivity in electronic applications. Constructed with durable Nylon housing and featuring a convenient Through Hole mount type, this terminal block ensures secure and reliable connections. The Push-In termination method, along with Electrolytic Copper contacts plated with Tin, guarantees excellent conductivity. With a pitch of 5mm, 2 poles, and 1 level, it offers versatility in circuit board layouts. The Gray housing color, UL 94V-0 flammability rating, and RoHS compliance ensure safety and environmental responsibility. Rated for 24A and 630V, accommodating wire sizes of 20-12 AWG, this terminal block is suitable for a wide range of high-power applications. Upgrade your connectivity with the 804-102.
| Product Category: | |
| Manufacturer: | WAGO |
| Manufacturer Part Number: | WAGO 804-102 |
| Series: | 804 |
| Housing Material: | Nylon |
| Mount Type: | Through Hole |
| Termination Method: | Push-In |
| Contact Material: | Electrolytic Copper |
| Contact Plating: | Tin |
| Pitch: | 5 mm |
| Number of Poles: | 2 |
| Number of Levels: | 1 |
| Housing Color: | Gray |
| Wire Size: | 20 - 12 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 24 A |
| Voltage Rating: | 630 V |
| Conductor Size: | 20 - 12 AWG |
| Part Aliases: | 51131922 |
| SKU: | WAG804-102 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
