255-406
PCB TERMINAL BLOCK
Part Aliases: WAGO 51141258
The 255-406, a high-performance PCB terminal block designed for secure and efficient wire connections in electronic applications. This terminal block, part of the 255 series, features a durable nylon housing in a sleek gray color, with a through hole mount type for easy installation. Termination is a breeze with the convenient cage clamp method, and the contacts are made of electrolytic copper with a tin plating for excellent conductivity and corrosion resistance. With 6 poles and 1 level, this terminal block accommodates multiple wires with a pitch of 5.08mm. Suitable for 28-12 AWG wires, it has a high current rating of 24A and a voltage rating of 630V, ensuring reliable performance. UL 94V-0 rated for safety, this RoHS compliant terminal block is ideal for a wide range of applications in the electronics industry.
| Product Category: | |
| Manufacturer: | WAGO |
| Manufacturer Part Number: | WAGO 255-406 |
| Series: | 255 |
| Housing Material: | Nylon |
| Mount Type: | Through Hole |
| Termination Method: | Cage Clamp |
| Contact Material: | Electrolytic Copper |
| Contact Plating: | Tin |
| Pitch: | 5.08 mm, 5 mm |
| Number of Poles: | 6 |
| Number of Levels: | 1 |
| Housing Color: | Gray |
| Wire Size: | 28 - 12 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 24 A |
| Voltage Rating: | 630 V |
| Conductor Size: | 28 - 12 AWG |
| Part Aliases: | 51141258 |
| SKU: | WAG255-406 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
