87421-0000

Heilind Number:	MOL87421-0000
Manufacturer:	Molex
Manufacturer Number:	87421-0000
Datasheet:	Product Literature
ECAD Model:

Description:

1.50mm Pico-SPOX Crimp Terminal, Female, Tin(Sn), 24-30 AWG, Reel

More >>

Specifications

Attribute	Value
Product Category:	Pin & Socket Housings & Contacts Pin & Socket Contacts
Manufacturer:	Molex
Manufacturer Part Number:	Molex 87421-0000
Series:	87421 - Pico-SPOX
Amperage:	2.5 A
Connector Type:	Pico-SPOX
Gender:	Female
Termination Method:	Crimp or Compression
Contact Material:	Phosphor Bronze
Contact Plating:	Tin
Voltage:	250 V
Circuit Application:	Signal
Contact Mating Area Plating:	Tin
Contact Mating Area Plating Thickness:	2.54 µm
Mating Cycles:	10
Contact Termination Plating Thickness:	2.540 µm
Wire Size:	24 AWG, 26 AWG
Connector System:	Wire to Board, Wire to Wire
Contact Termination Plating:	Tin
Wire Insulation Diameter:	.95 - 1.2 mm
Part Aliases:	0874210000
SKU:	MOL87421-0000

Detailed Description

Introducing the 87421-0000, a high-performance Pico-SPOX connector designed for reliable signal transmission. With a low amperage rating of 2.5 A and a voltage capacity of 250 V, this female connector is perfect for various electronic applications. Its phosphor bronze contact material with tin plating ensures excellent conductivity and corrosion resistance. The crimp or compression termination method accommodates 24-26 AWG wires, with a wire insulation diameter of .95-1.2 mm. Engineered for durability, this connector offers a mating cycle of 10, making it ideal for both wire-to-wire and wire-to-board connections. With RoHS compliance and a sleek design, the 87421-0000 is a top choice for your connectivity needs.

Frequently Bought Together

Product	Part #	Description	Stock
	Molex 22-01-3037	KK 254 Crimp Housing, Friction Ramp with Polarizing Ribs, 3 Circuits, Natural
	Molex 22-01-3047	KK 254 Crimp Housing, Friction Ramp with Polarizing Ribs, 4 Circuits, Natural
	Molex 22-01-3067	KK 254 Crimp Housing, Friction Ramp with Polarizing Ribs, 6 Circuits, Natural
	Molex 39-00-0038	Mini-Fit Female Crimp Terminal, Tin (Sn) over Copper (Cu) Plated Brass, Double 22+22 or Single 24-18 AWG, Reel
	Molex 39-00-0046	Mini-Fit Female Crimp Terminal, Tin (Sn) over Copper (Cu) Plated Brass, 28-22 AWG, Reel
	Molex 39-00-0059	Mini-Fit Female Crimp Terminal, Tin (Sn) over Phosphor Bronze, Double 22+22 or Single 24-18 AWG, Reel
	Molex 39-01-2020	Mini-Fit Jr. Receptacle Housing, Dual Row, 2 Circuits, UL 94V-2, Natural
	Molex 39-01-2045	Mini-Fit Jr. Receptacle Housing, Dual Row, 4 Circuits, UL 94V-0, Natural
	Molex 39-01-2245	Mini-Fit Jr. Receptacle Housing, Dual Row, 24 Circuits, UL 94V-0, Natural
	Molex 39-01-4051	Mini-Fit Jr. Receptacle Housing, Single Row, 5 Circuits, UL 94V-0, Natural
	Molex 43025-0600	Micro-Fit 3.0 Receptacle Housing, Dual Row, 6 Circuits, UL 94V-0, Low-Halogen, Black
	Molex 50-57-9405	SL Crimp Housing, Single Row, Version G, Positive Latch, 5 Circuits, Black
	Molex 50079-8000	1.25mm Pitch PicoBlade Crimp Terminal, 26-28 AWG, Reel
	Molex 87439-0400	1.50mm Pitch Pico-SPOX Wire-to-Board Housing, 4 Circuits, Off-White Housing
	Molex 87439-0600	1.50mm Pitch Pico-SPOX Wire-to-Board Housing, 6 Circuits, Off-White Housing
	Molex 87439-0800	1.50mm Pitch Pico-SPOX Wire-to-Board Housing, 8 Circuits, Off-White Housing

Product Change Notice

Effective Date	Description of Change	Download
05/31/2020	508547 - Packaging Method/Quantity Changing. increasing the DU from 15k to 20k and reduce filament tape qty from 8 pc to 4 pc for 87421 terminal series.	Download
12/07/2019	507801 - Tooling Capacity Change.	Download
01/16/2017	502125 - Supplier Change. This letter is to inform you that Molex is adding a new supplier or the supplier is making a change affecting the part(s) identified in this notice. There will be no negative impact to product performance as a result of this change.	Download
