| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 78172-0410 |
| Series: | 78172 - Pico-EZmate |
| Amperage: | 1.5 A |
| Connector Type: | Pico-EZmate |
| Gender: | Female |
| Termination Method: | Crimp or Compression |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold |
| Voltage: | 50 V AC/DC |
| Circuit Application: | Signal |
| Contact Mating Area Plating: | Gold |
| Contact Mating Area Plating Thickness: | .1 µm |
| Mating Cycles: | 10 |
| Contact Termination Plating Thickness: | .1 µm |
| Wire Size: | .055 - .089 mm², 28 AWG, 30 AWG |
| Connector System: | Wire to Board, Wire to Wire |
| Contact Termination Plating: | Gold |
| Wire Insulation Diameter: | .6 - .7 mm |
| Part Aliases: | 0781720410 |
| SKU: | MOL78172-0410 |
78172-0410
| Heilind Number: | MOL78172-0410 |
| Manufacturer: | Molex |
| Manufacturer Number: | 78172-0410 |
| Datasheet: | Application Specification |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the 78172-0410, a high-performance Pico-EZmate Wire-to-Board Crimp Terminal designed for seamless connectivity in electronic applications. With a low-profile 0.10 pitch, this female terminal is engineered to accommodate 28-30 AWG wires, ensuring precision and reliability in signal transmission. Constructed from durable copper alloy with gold plating, it guarantees excellent conductivity and corrosion resistance, even in harsh environments. Rated for 1.5 A and 50 V AC/DC, this terminal is suitable for a wide range of circuit applications. Its crimp or compression termination method offers easy and secure installation, while the gold-plated contact mating area ensures long-lasting performance with minimal signal loss. Compliant with RoHS standards, the 78172-0410 is the perfect choice for high-speed and high-density connectivity in various industries.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | Molex 105308-1210 | Nano-Fit Receptacle Housing, TPA Capable, 2.50mm Pitch, Dual Row, 10 Circuits, Black, Glow-Wire Capable |  |
 | Molex 172256-3102 | Ultra-Fit Tangless Receptacle Housing, 3.50mm Pitch, Single Row, 2 Circuits, Black, Glow-Wire Capable | |
 | Molex 172258-3104 | Ultra-Fit Tangless Receptacle Housing, 3.50mm Pitch, Dual Row, 4 Circuits, Black, Glow-Wire Capable | |
 | Molex 172258-3110 | Ultra-Fit Tangless Receptacle Housing, 3.50mm Pitch, Dual Row, 10 Circuits, Black, Glow-Wire Capable | |
 | Molex 19003-0068 | InsulKrimp Quick Disconnect, Female, for 24-26 (0.20-0.12mm?), Box, Tab 4.75 x 0.81mm | |
 | Molex 19057-0093 | RING AVIKRIMP (B-537-10) | |
 | Molex 42816-0212 | 10.00mm Pitch Mini-Fit Sr. Receptacle Housing, Single Row, 2 Circuit, Black | |
 | Molex 44300-0800 | Micro-Fit BMI Plug Housing, Dual Row, Panel Mount, 8 Circuits, Black | |
 | Molex 44478-1111 | Mini-Fit HCS Crimp Terminal, 18-20 AWG, Reel, Copper (Cu) Alloy, Tin (Sn) | |
 | Molex 51021-0300 | 1.25mm Pitch PicoBlade Wire-to-Wire and Wire-to-Board Housing, Female, 3 Circuits, Natural | |
 | Molex 51110-0856 | 2.00mm Pitch, Milli-Grid Receptacle Housing, 8 Circuits, with Center Locking Ramp and Side Polarization Keys, Lead-Free | |
 | Molex 78172-0002 | Pico-EZmate Wire-to-Board Receptacle Housing, with Side Friction Locks, 2 Circuits, Black | |
 | Molex 78172-0004 | Pico-EZmate Wire-to-Board Receptacle Housing, with Side Friction Locks, 4 Circuits, Black | |
 | Molex 78172-0005 | Pico-EZmate Wire-to-Board Receptacle Housing, with Side Friction Locks, 5 Circuits, Black | |
 | Molex 83421-9014 | 1.27mm Pitch Commercial Micro D, Cable Receptacle Kit, 9 Circuits | |
 | Molex 87421-0000 | 1.50mm Pico-SPOX Crimp Terminal, Female, Tin(Sn), 24-30 AWG, Reel | |
 | Molex 87439-0400 | 1.50mm Pitch Pico-SPOX Wire-to-Board Housing, 4 Circuits, Off-White Housing | |
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 04/15/2022 | 510932 - Change to Product. Recepticle terminal drawing revision, consolidate 2 terminal drawings into 1 drawing terminal, provide terminal contact dimensions and add barrel tolerances on updated drawing views | Download | |||
| 12/27/2018 | 505426 - Supplier Change. This letter is to inform you that Molex is adding a new supplier or the supplier is making a change affecting the part(s) identified in this notice. There will be no negative impact to product performance as a result of this change. | Download | |||
