| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 505572-1000 |
| Series: | 505572 - Micro-Lock Plus |
| Amperage: | 3 A |
| Connector Type: | Micro-Lock PLUS |
| Gender: | Female |
| Termination Method: | Crimp or Compression |
| Contact Material: | Copper Alloy |
| Voltage: | 250 V AC/DC |
| Circuit Application: | Signal |
| Contact Mating Area Plating: | Tin |
| Mating Cycles: | 30 |
| Wire Size: | 22 AWG, .22 mm², 24 AWG, 26 AWG, .3 mm² |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | .9 - 1.5 mm |
| Part Aliases: | 5055721000 |
| SKU: | MOL505572-1000 |
505572-1000
Specifications
Detailed Description
Introducing the 505572-1000, a high-performance female Micro-Lock PLUS connector designed for signal applications. This connector, part of the 505572 Micro-Lock Plus series, features a low amperage rating of 3 A and is suitable for wire-to-board termination using crimp or compression methods. Crafted from durable copper alloy with tin plating on the contact mating area, it ensures reliable conductivity with a maximum voltage of 250 V AC/DC. With a versatile wire size compatibility ranging from 24-26 AWG (.3-.22 mm²) and a mating cycle of 30, this connector guarantees longevity and efficiency in various electronic systems. RoHS compliant and in stock, the 505572-1000 is the ideal choice for applications demanding high reliability in signal transmission.
