| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 500075-1517 |
| Color: | Black |
| Series: | 500075 - USB 2.0 - USB OTG (On-The-Go) |
| Amperage: | 1 A |
| Connector Type: | USB, USB OTG (On-The-Go) |
| Gender: | Female |
| Number of Contacts: | 5 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Copper Alloy |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| Body Orientation: | Vertical |
| Pitch: | 8 mm |
| Voltage: | 30 V AC/DC |
| Shield Type: | Full Shield |
| Number of Ports: | 1 |
| Orientation: | Vertical |
| USB Type: | Mini-B |
| Component Type: | Receptacle |
| Tail Length: | 2 mm |
| Packaging: | Tray |
| Operating Temperature Range: | -40 - 85 °C |
| Contact Mating Area Plating: | Gold |
| Number of Contacts Loaded: | 5 |
| PCB Locator: | Yes |
| Shielded: | Yes |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | .8 mm |
| Supplier Product Group: | High Speed Cage & Connector Assemblies |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin |
| Termination Pitch: | .8 mm |
| Lock to Mating Part: | Yes |
| Surface Mount Compatible: | No |
| Part Aliases: | 5000751517 |
| SKU: | MOL500075-1517 |
500075-1517
| Heilind Number: | MOL500075-1517 |
| Manufacturer: | Molex |
| Manufacturer Number: | 500075-1517 |
| Datasheet: | Product Specification |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the 500075-1517, a high-speed USB connector designed for reliable data transfer in a compact form. This Mini-B receptacle features 5 contacts loaded for optimal connectivity, with through-hole solder tails and shell tabs ensuring secure attachment to the PCB. Its vertical orientation and low-profile design make it ideal for space-constrained applications. With a durable copper alloy construction and gold contact mating area plating, this connector guarantees long-lasting performance, even in harsh environments. Rated for 1A and 30V AC/DC, it is suitable for a wide range of devices. RoHS compliant and featuring full shielding, the 500075-1517 offers peace of mind in terms of environmental responsibility and signal integrity. Upgrade your connectivity with this versatile and reliable USB connector.
