50-84-1095
2.13mm Diameter MLX Power Crimp Housing Plug, 9 Circuits, Natural
Part Aliases: Molex 0050841095 Molex 4202109C
The 50-84-1095, a high-performance 20A/11A MLX connector designed for power applications. With a durable nylon housing and three rows of nine contacts, this connector ensures reliable and secure wire-to-wire or wire-to-board connections. Featuring a 6.35mm pitch and operating temperature range of -55 to 105°C, it is suitable for a wide range of industrial environments. CSA and UL certified, as well as RoHS compliant, guaranteeing safety and quality standards. The polarized plug design and locking feature provide added security, making it ideal for high vibration applications. Upgrade your power connectivity with the 50-84-1095 for dependable performance in demanding conditions.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 50-84-1095 |
| Color: | Natural |
| Series: | 42021 - MLX |
| Amperage: | 11 A, 20 A |
| Connector Type: | MLX |
| Gender: | Plug |
| Housing Material: | Nylon |
| Number of Contacts: | 9 |
| Number of Rows: | 3 |
| Pitch: | 6.35 mm |
| Material: | Nylon |
| Keying: | No |
| Packaging: | Bag |
| Operating Temperature Range: | -55 - 105 °C |
| Circuit Application: | Power |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Board, Wire to Wire |
| CSA Agency Certification: | LR19980 |
| UL Agency Certification: | E29179 |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0050841095 4202109C |
| Contact Detail: | 9 |
| SKU: | MOL50-84-1095 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
Product Change Notice
| Effective Date | Description of Change | Download |
|---|---|---|
| 08/01/2019 | 507498 - Packaging Method/Quantity Changing. This letter is to inform you that the part(s) referenced in this notice will undergo packaging specification changes that may include new container sizes, quantities or changes to the label. No changes will be made to the product as a result of this change. | Download |
| 10/01/2017 | 503068 - Equipment Transfer, Production Transfer or Rearrangement. | Download |
| 08/17/2017 | 502888 - Change to Product. This letter is to inform you that changes are being made to the part(s) identified in this Notice. The change may affect the fit, form, function or appearance of the parts, or it may result in a change to the specification. | Download |
