| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 39-00-0217 |
| Series: | 5556 - Mini-Fit |
| Amperage: | 9 A |
| Connector Type: | Mini-Fit |
| Gender: | Female |
| Termination Method: | Crimp or Compression |
| Contact Material: | Phosphor Bronze |
| Contact Plating: | Tin |
| Voltage: | 600 V |
| Circuit Application: | Power |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | 2.54 µm |
| Mating Cycles: | 30 |
| Contact Termination Plating Thickness: | 1.27 µm |
| Wire Size: | 16 AWG |
| Connector System: | Wire to Board, Wire to Wire |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | 1.8 - 3.1 mm |
| Part Aliases: | 0039000217 5556-PBS3P |
| SKU: | MOL39-00-0217 |
39-00-0217
| Heilind Number: | MOL39-00-0217 |
| Manufacturer: | Molex |
| Manufacturer Number: | 39-00-0217 |
| Datasheet: | Packaging Specifications |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the Mini-Fit Female Crimp Terminal, a high-performance connector designed for power applications. Made of durable Tin (Sn) over Phosphor Bronze, this terminal is suitable for 16 AWG wires. It features a convenient reel packaging for easy handling and storage. With a current rating of 9 A and a voltage capacity of 600 V, it ensures reliable power transmission. The Phosphor Bronze contact material with Tin plating offers excellent conductivity and corrosion resistance. Engineered for wire-to-wire or wire-to-board connections, this terminal is versatile and easy to install with a crimp or compression termination method. With its compact Mini-Fit design and ROHS compliance, it is ideal for a wide range of industries. Elevate your connectivity solutions with the Mini-Fit Female Crimp Terminal.
