| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 34729-0160 |
| Color: | Black |
| Series: | 34729 - Stac64 |
| Amperage: | 10 A |
| Connector Type: | Stac64 |
| Number of Contacts: | 16 |
| Number of Rows: | 2 |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Body Orientation: | Straight |
| Pitch: | 2.54 mm |
| Voltage: | 500 V |
| Material: | High Temperature Thermoplastic |
| Orientation: | Vertical |
| Keying: | No |
| Tail Length: | 3.33 mm |
| Packaging: | Tray |
| Pick and Place: | Without Pick and Place Cover |
| Operating Temperature Range: | -40 - 100 °C |
| Circuit Application: | Signal |
| Contact Mating Area Plating: | Tin |
| Number of Contacts Loaded: | 16 |
| Mating Cycles: | 10 |
| PCB Locator: | Yes |
| PCB Retention: | Without |
| Polarized to PCB: | Yes |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | 1.6 mm |
| Supplier Product Group: | PCB Socket Receptacles |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin |
| Termination Pitch: | 2.54 mm |
| Glow Wire Capable: | No |
| Guide to Mating Part: | No |
| Lock to Mating Part: | Yes |
| Stackable: | Yes |
| Surface Mount Compatible: | No |
| Product Name: | Stac64 |
| Part Aliases: | 0347290160 34729-160 |
| SKU: | MOL34729-0160 |
34729-0160
| Heilind Number: | MOL34729-0160 |
| Manufacturer: | Molex |
| Manufacturer Number: | 34729-0160 |
| Datasheet: | Packaging Specifications |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the Molex Stac64 Receptacle Assembly, featuring 16 circuits with Polarization A for secure connections. This black tray-mounted assembly is designed for signal applications, with each of its 16 contacts capable of handling up to 10 A of current at 500 V. Constructed of high temperature thermoplastic with tin contact mating area plating, this connector offers reliable performance in a wide range of operating environments, from -40 to 100 °C. With a straight body orientation, 2.54 mm pitch, and through hole termination method, it ensures easy and secure installation on a 1.6 mm PCB. RoHS compliant and featuring PCB locator and retention, this Stac64 assembly is a dependable solution for your board-to-wire connectivity needs.
