| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 33472-4802 |
| Color: | Gray (Light) |
| Series: | 33472 - MX150 |
| Connector Type: | MX150 |
| Gender: | Receptacle |
| Number of Contacts: | 8 |
| Number of Rows: | 2 |
| Pitch: | 3.5 mm |
| Material: | Modified Polystyrene Alloy |
| Keying: | Yes |
| Polarization: | B |
| Operating Temperature Range: | -40 - 125 °C |
| Circuit Application: | Power |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Board, Wire to Wire |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Part Aliases: | 0334724802 |
| SKU: | MOL33472-4802 |
33472-4802
| Heilind Number: | MOL33472-4802 |
| Manufacturer: | Molex |
| Manufacturer Number: | 33472-4802 |
| Datasheet: | Product Specification |
| ECAD Model: | |
Description:
MX150 Sealed Female Connector, Dual Row, 8 Circuits, Polarization B, without Connector Position Assurance, Light Gray
More >>Specifications
Detailed Description
Introducing the 33472-4802 MX150 Sealed Female Connector, a versatile solution for your power circuit applications. This dual-row connector features 8 circuits, each meticulously designed for optimal performance. With Polarization B and without Connector Position Assurance, it offers seamless connectivity in any project. The light gray color adds a sleek touch, while the Modified Polystyrene Alloy construction ensures durability even in harsh environments. Operating flawlessly in temperatures ranging from -40 to 125 °C, this connector is reliable for a wide range of applications. Whether for wire-to-wire or wire-to-board connections, it guarantees a secure fit with its lock to mating part feature. RoHS compliant and in stock for immediate shipping, the 33472-4802 is the perfect choice for your connectivity needs.
