| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 22-29-2021 |
| Gender: | Male |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| Contact Material: | Brass |
| Contact Plating: | Gold, Tin |
| Pitch: | 2.54 mm |
| Shrouded: | Yes |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 4 A |
| Voltage Rating: | 500 V |
| Operating Temperature: | -40 to 80 °C |
| Mounting Angle: | Straight |
| Mounting Type: | Through Hole |
| PCB Connector Type: | PCB Mount Header |
| SKU: | MOL22-29-2021 |
22-29-2021
Specifications
Detailed Description
The 22-29-2021 KK 254 Wire-to-Board Header offers reliable vertical connectivity with a friction lock feature, ideal for secure board-to-wire applications. With 2 gold-plated (Au) circuits, it ensures excellent signal transmission, while the natural white color and straight body orientation add to its versatility. Constructed with brass contacts and nylon material, it guarantees durability and a maximum voltage of 500 V. This through-hole termination header, with a pitch of 2.54 mm, is UL and CSA certified, meeting quality and safety standards. Perfect for PCB connectors in various industries, it is also RoHS compliant, making it a sustainable choice for your projects.
