22-28-4023

ICC Number:	MOL22-28-4023
Manufacturer:	Molex
Manufacturer Number:	22-28-4023
Datasheet:	Datasheet
ECAD Model:

Description:

KK 254 Breakaway Header, Vertical, 2 Circuits, 0.38µm Gold (Au) Plating, Mating Pin Length 6.09mm

More >>

Specifications

Attribute	Value
Product Category:	Connectors PCB Connectors
Manufacturer:	Molex
Manufacturer Part Number:	Molex 22-28-4023
Gender:	Male
Number of Contacts:	2
Number of Rows:	1
Contact Material:	Brass
Contact Plating:	Gold, Tin
Pitch:	2.54 mm
Shrouded:	No
Flammability Rating:	UL 94V-0
Current Rating:	4 A
Voltage Rating:	500 V
Operating Temperature:	-40 to 80 °C
Mounting Angle:	Straight
Mounting Type:	Through Hole
PCB Connector Type:	PCB Mount Header
SKU:	MOL22-28-4023

Detailed Description

Introducing the 22-28-4023, a black KK 254 Breakaway Header designed for vertical mounting with 2 circuits and a current rating of 4 A. Constructed with brass contacts and high temperature thermoplastic, this connector ensures reliable performance in demanding environments. Featuring gold contact mating area plating, it offers enhanced signal integrity. With a pitch of 2.54 mm and through-hole termination, it is suitable for various PCB applications. UL and CSA certified, as well as RoHS compliant, this header meets international quality standards. Perfect for board-to-board and wire-to-board connections, it is a versatile and dependable solution for your connectivity needs.
