| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 19202-0031 |
| Color: | Blue |
| Series: | 19202 - Butt - NylaKrimp |
| Connector Type: | Butt, NylaKrimp |
| Contact Material: | Copper |
| Contact Plating: | Tin |
| Voltage: | 600 V |
| Insulation Material: | Nylon (PA) |
| Maximum Voltage: | 600 V |
| Operating Temperature Range: | -55 - 105 °C |
| Contact Mating Area Plating: | Tin |
| Wire Size: | 14 AWG, 16 AWG, 1.3 - 2 mm² |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | 4.32 mm |
| Barrel Type: | Closed - Brazed |
| Material Flammability Standard: | 94V-2 |
| Part Aliases: | 0192020031 BS-N-331 |
| SKU: | MOL19202-0031 |
19202-0031
| Heilind Number: | MOL19202-0031 |
| Manufacturer: | Molex |
| Manufacturer Number: | 19202-0031 |
| Datasheet: | Product Specification |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the 19202-0031 NylaKrimp Butt Splice, a reliable and durable connector designed for 14-16 AWG wires. Featuring a vibrant blue color for easy identification, this splice is part of the 19202 Butt NylaKrimp series. Constructed with copper contacts and tin plating, it ensures excellent conductivity and corrosion resistance, with a maximum voltage of 600 V. The nylon insulation material and operating temperature range of -55 to 105 °C guarantee safe and efficient performance. Suitable for 1.3-2 mm² wire sizes, this tin-plated splice with a closed-brazed barrel is RoHS compliant, making it an environmentally friendly choice for various applications. Keep your connections secure with the 19202-0031 NylaKrimp Butt Splice.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | Molex 09-50-1061 | 3.96mm Pitch SPOX Crimp Housing, Female, with Friction Ramp, 6 Circuits, Natural |  |
 | Molex 19002-0031 | Avikrimp Fully Insulated Quick Disconnect, Female, for 14-16 AWG Wire, Box | |
 | Molex 19006-0005 | Avikrimp Quick Disconnect, for 18-22 AWG Wire, Female Flag, Tab 4.75 x 0.51mm | |
 | Molex 19007-0024 | Flag InsulKrimp Quick Disconnect, Female, for 14-16 (2.00-1.30mm?) Wire, Mylar Tape, Tab 6.35 x 0.81mm | |
 | Molex 19007-0036 | Flag InsulKrimp Quick Disconnect, Female, for 14-16 (2.00-1.30mm?) Wire, Mylar Tape, Tab 4.75 x 0.81mm | |
 | Molex 19164-0013 | Perma-Seal Butt Splice for 18-22 AWG Wire | |
 | Molex 19164-0044 | Perma-Seal Butt Splice for 14-16 AWG Wire | |
 | Molex 19202-0013 | NylaKrimp Butt Splice for 18-22 AWG Wire | |
 | Molex 19202-0049 | NylaKrimp Butt Splice for 10-12 AWG Wire | |
 | Molex 19215-0009 | VersaKrimp Butt Splice for 18-22 AWG Wire | |
 | Molex 19215-0018 | VersaKrimp Butt Splice for 14-16 AWG Wire | |
 | Molex 19215-0028 | VersaKrimp Butt Splice for 10-12 AWG Wire | |
 | Molex 19221-0454 | Compression Style Ring Tongue Terminal for 4 AWG Wire, Stud Size 1/2 (M12), Tin Plated | |
 | Molex 33012-3003 | MX150 Female Terminal Sealed, Tin Plating, 22 AWG, Left Reel Payoff | |
 | Molex 43030-0003 | Micro-Fit 3.0 Crimp Terminal, Female, with Select Gold (Au) Plated Phosphor Bronze Contact, 24-20 AWG, Reel | |
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 02/18/2019 | 506408 - Packaging Method/Quantity Changing. This letter is to inform you that the part(s) referenced in this notice will undergo packaging specification changes that may include new container sizes, quantities or changes to the label. No changes will be made to the product as a result of this change. | Download | |||
Availability
Immediate Shipment:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
Additional Resources
| Attribute | Value |
|---|---|
| Molex: | 19202-0031 |
| Other Names: | 0192020031 BS-N-331 |
