| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 19164-0033 |
| Series: | 19164 - Perma-Seal |
| Connector Type: | Perma-Seal |
| Contact Plating: | Tin |
| Stud Size: | 8 (M4) |
| Insulation Material: | NiAc |
| Contact Mating Area Plating: | Tin |
| Wire Size: | 14 AWG, 16 AWG, 1.23 - 1.94 mm² |
| Wire Insulation Diameter: | 5.97 mm |
| Barrel Type: | Closed |
| Part Aliases: | 0191640033 SB-237-08 |
| SKU: | MOL19164-0033 |
19164-0033
| Heilind Number: | MOL19164-0033 |
| Manufacturer: | Molex |
| Manufacturer Number: | 19164-0033 |
| Datasheet: | Product Specification |
| ECAD Model: | |
Specifications
Detailed Description
The 19164-0033 is a high-quality Perma-Seal Ring Tongue Terminal designed for 14-16 AWG wires, featuring a durable tin contact plating for reliable conductivity. With a stud size of 8 (M4), this terminal is suitable for various applications. Its NiAc insulation material and closed barrel design ensure secure and safe connections, accommodating wire insulation diameters of up to 5.97 mm. RoHS compliant, this terminal guarantees environmentally friendly usage. Perfect for crimping tasks, it is a essential component in any electrical assembly project.
