| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 19054-0037 |
| Color: | Red |
| Series: | 19054 - InsulKrimp |
| Connector Type: | InsulKrimp |
| Termination Method: | Crimp or Compression |
| Contact Material: | Copper |
| Stud Size: | 8 (M4) |
| Insulation Material: | PVC |
| Packaging: | Carton |
| Operating Temperature Range: | 105 °C |
| Contact Mating Area Plating: | Tin |
| Wire Size: | 18 AWG, 20 AWG, 22 AWG, .25 - 1.5 mm² |
| CSA Agency Certification: | LR18689 |
| UL Agency Certification: | E32244 |
| Wire Insulation Diameter: | 3.68 mm |
| Barrel Type: | Closed |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0190540037 A-221-08X |
| SKU: | MOL19054-0037 |
19054-0037
Specifications
Detailed Description
Introducing the 19054-0037 RING INSULKRIMP (A-221-08X), a high-quality crimp or compression terminal for secure wire connections. This red InsulKrimp connector, part of the 19054 series, features a durable PVC insulation and copper contact material with tin plating, ensuring reliable performance in a wide range of applications. Suitable for wire sizes ranging from 22 AWG to 18 AWG, or 0.25 to 1.5 mm², and with a stud size of 8 (M4), it offers versatility in installation. With UL (E32244) and CSA (LR18689) agency certifications, this terminal meets stringent safety standards. Its closed barrel design and RoHS compliance guarantee environmental responsibility. Trust the 19054-0037 for efficient and compliant wire termination.
