| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 19019-0008 |
| Color: | Red |
| Series: | 19019 - Avikrimp |
| Connector Type: | Avikrimp, Quick Disconnect |
| Gender: | Female |
| Contact Material: | Brass |
| Contact Plating: | Tin |
| Voltage: | 300 V |
| Material: | Brass |
| Insulation Material: | Nylon (PA) |
| Compatible Tab Width: | 4.75mm |
| Compatible Tab Thickness: | 0.81mm |
| Orientation: | Straight |
| Insulation Type: | Partial |
| Packaging: | Bag |
| Operating Temperature Range: | -65 - 105 °C |
| Contact Mating Area Plating: | Tin |
| Polarized to Mate: | No |
| Wire Size: | 18 AWG, 20 AWG, 22 AWG |
| CSA Agency Certification: | LR18689 |
| UL Agency Certification: | E79133 |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | 2.9 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | No |
| Material Flammability Standard: | 94V-2 |
| Part Aliases: | 0190190008 AA-8137-032 |
| SKU: | MOL19019-0008 |
19019-0008
| Heilind Number: | MOL19019-0008 |
| Manufacturer: | Molex |
| Manufacturer Number: | 19019-0008 |
| Datasheet: | RoHS Certificate of Compliance |
| ECAD Model: | |
Description:
Avikrimp Quick Disconnect, Female, for 18-22 (0.80-0.35mm?) Wire, Box, Tab 4.75 x 0.81mm
More >>Specifications
Detailed Description
The 19019-0008 is a high-quality Avikrimp Quick Disconnect terminal designed for efficient wire connections. Featuring a female connector type, it is compatible with 18-22 AWG wires. Constructed with brass and tin plating, it ensures reliable conductivity with a voltage rating of 300V. The red nylon insulation accommodates a 4.75 x 0.81mm tab, offering partial insulation for safety. Certified by CSA and UL, this RoHS-compliant terminal guarantees quality and performance. Suitable for a wide range of applications, it operates effectively in temperatures ranging from -65 to 105°C. Upgrade your connectivity solutions with the 19019-0008.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | Molex 16-02-0102 | SL Crimp Terminal, Series 70058, Female, 24-22 AWG, with Tin (Sn) Plated Contact |  |
 | Molex 19003-0040 | InsulKrimp Female Quick Disconnect, for 14-16 AWG Wire | |
 | Molex 19193-0346 | VersaKrimp Ring Tongue Terminal for 2/0 AWG Wire | |
 | Molex 19193-0360 | VersaKrimp Ring Tongue Terminal for 3/0 AWG Wire | |
