| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 19003-0026 |
| Color: | Red |
| Series: | 19003 - InsulKrimp |
| Connector Type: | InsulKrimp, Quick Disconnect |
| Gender: | Female |
| Termination Method: | Crimp or Compression |
| Contact Material: | Brass |
| Contact Plating: | Tin |
| Voltage: | 600 V |
| Material: | Brass, Nylon |
| Insulation Material: | Nylon (PA) |
| Compatible Tab Width: | 2.79mm |
| Compatible Tab Thickness: | 0.51mm |
| Orientation: | Straight |
| Insulation Type: | Full |
| Operating Temperature Range: | -65 - 105 °C |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | 4.064 µm |
| Contact Termination Plating Thickness: | 4.064 µm |
| Polarized to Mate: | No |
| Wire Size: | 18 AWG, 20 AWG, 22 AWG |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | 3.43 mm |
| Glow Wire Capable: | Yes |
| Lock to Mating Part: | No |
| Material Flammability Standard: | 94V-2 |
| Part Aliases: | 0190030026 AA-2204T |
| SKU: | MOL19003-0026 |
19003-0026
| Heilind Number: | MOL19003-0026 |
| Manufacturer: | Molex |
| Manufacturer Number: | 19003-0026 |
| Datasheet: | Product Specification |
| ECAD Model: | |
Description:
InsulKrimp Quick Disconnect, Female, for 18-22 (0.80-0.35mm?), Mylar Tape, Tab 2.79 x 0.51mm
More >>Specifications
Detailed Description
The 19003-0026 InsulKrimp Quick Disconnect is a female connector designed for 18-22 AWG wires with a Mylar Tape insulation. Featuring a red color for easy identification, this straight orientation connector has a tab size of 2.79 x 0.51mm. Constructed with brass contacts and tin plating, it ensures reliable conductivity with a voltage rating of 600V. The nylon and brass construction, along with nylon insulation, make it durable and suitable for a wide operating temperature range. With RoHS compliance and glow wire capability, this connector guarantees safety and performance in various applications.
